Micron 0.1g High Accuracy Automatic Conveyor Belt Checkweigher Machine Flapper System JZ-W100g

sorting speed : 20bag/minutes

belt material : PU

HBM load cell : (original from Germany)

belt standard : FDA

Place of Origin : Guangdong, China

MOQ : 1

Machine material : SUS304

Power Supply : 220V

accuracy : +/-0.1 grams

Model Number : JZ-W100g

waterproof : IP66

display type : 10" color touch screen

Contact Now

High Quality 0.1g High Accuracy Automatic Conveyor Belt Check Weigher Machine with Flapper JZ-W100g

The JZ-W100g Check Weigher is a high-precision automatic weighing system designed to verify whether individual package weights conform to preset specifications. The system automatically removes overweight and underweight products using various rejection devices while allowing qualified packages to proceed to the next equipment.

Applications

Quality control and weight verification for packaged products
Automatic rejection of non-conforming packages
Production line integration for continuous operation

Key Features

PLC and 10" color touch screen with intelligent compact design
Auto program setting adjustment for enhanced stability and ease of operation
HBM load cell (original from Germany) ensures high accuracy and stability
Solid SUS304 structure provides stable performance and precise weighing
Multiple rejection options: reject arm, air blast, or pneumatic pusher
Tool-free belt disassembly for easy cleaning and maintenance
Emergency switch installation for user-friendly operation
Optional arm device for clear production situation display
Can record up to 10 different product parameters

Technical Specifications

Model	JZ-W100g
Control System	10" color touch screen
Weighing Range	3-100 grams
Sorting Speed	60-80 bags/minute
Conveyor Speed	40 m/minute
Accuracy	±0.1 grams
Minimum Scale	0.01 grams
Weigh Belt	300L/400L * 130W mm
Conveyor Height	750mm ±50mm
Auto Rejector System	Reject Arm / Air Blast / Pneumatic Pusher / Divided-flow Style
Waterproof Rating	IP66
Power Supply	220V/50HZ or 60HZ Single Phase
Machine Material	304 Stainless Steel
Interface	Weight transmission to ink-jet printer (requires customer protocol)
Packing Dimension	1450L * 400W * 1510H mm
Gross Weight	150 kg

Optional Accessories

Network data management software
Front feeding FBC feedback control software
Printer
Indicator lamp
